Free To Air radiochannels (DVB-S / MPEG-2 / FTA):
| | | | |
| |
12284V, sr: 27500, fec: 3/4
ECEE (BSS) (Sirius-4) | | |
|
|
Free To Air TV-channels (DVB-S / MPEG-4 / FTA):
| | | | |
| |
12130V, sr: 27500, fec: 3/4
ECEE (BSS) (Sirius-4)Uplink - SES Astra
19.05.2023 | RZR | ukr.
| FTA | | |
12284V, sr: 27500, fec: 3/4
ECEE (BSS) (Sirius-4) | | | | |
|
Crypted channels (DVB-S / MPEG-4 / scrambled):
| | | | |
| |
12015V, sr: 27500, fec: 3/4
Scandinavia (BSS) (Sirius-4)Package: Viasat
| | |
|
Crypted channels (DVB-S2 / MPEG-4 / scrambled):
| | | | |
| |
11265H, sr: 30000, fec: 3/4Package: Viasat
| | |
|
Free To Air channels (DVB-S2 / MPEG-4 / FTA):
| | | | |
| |
11747V, sr: 30000, fec: 3/4
ECEE (BSS) (Sirius-4) | | |
|
FTA channels T2-MI (DVB-S2 / MPEG-4 / T2-MI / FTA):
| | | | |
| |
12073H, sr: 30000, fec: 2/3
ECEE (BSS) (Sirius-4)Uplink - SES Astra
| | |
|
Encrypted channels HEVC (DVB-S2 / HEVC / scrambled):
| | | | |
| |
12092V, sr: 30000, fec: 2/3 | | |
|
| Footprints. Карты покрытий. Hartile de acoperire. |
| # | Beam | Transponders, MHz. Мультиплексы, МГц. | Downlink, MHz. Приёмные частоты, МГц. | Numbers of TP. Количество ТП | Max EIRP, dBW. Макс. ЭИИМ, дБВт | Official site. Офиц. сайт | | 51 | Scandinavia (BSS)
Sirius-4 | 11727H 11785V 11804H 11823V 11843H 11862V 11881H 11900V 11919H 11938V 11958H 11977V 11996H 12015V 12034H 12054V 12456H 12476V | 11700 - 12500 MHz | 20 x 33 MHz | 0 | |   | bbcode:
51 | | # | Beam | Transponders, MHz. Мультиплексы, МГц. | Downlink, MHz. Приёмные частоты, МГц. | Numbers of TP. Количество ТП | Max EIRP, dBW. Макс. ЭИИМ, дБВт | Official site. Офиц. сайт | | 52 | Scandinavia (FSS)
Sirius-4 | 12580V | 12500 - 12750 MHz | 3 x 72 MHz | 0 | |  | bbcode:
52 | | # | Beam | Transponders, MHz. Мультиплексы, МГц. | Downlink, MHz. Приёмные частоты, МГц. | Numbers of TP. Количество ТП | Max EIRP, dBW. Макс. ЭИИМ, дБВт | Official site. Офиц. сайт | | 53 | ECEE (BSS)
Sirius-4 | 11747V 11766H 12073H 12111H 12130V 12169V 12188H 12207V 12226H 12243V 12284V 12303H 12322V 12341H 12360V 12380H 12399V | 11700 - 12500 MHz | 20 x 33 MHz | 0 | |   | bbcode:
53 | | # | Beam | Transponders, MHz. Мультиплексы, МГц. | Downlink, MHz. Приёмные частоты, МГц. | Numbers of TP. Количество ТП | Max EIRP, dBW. Макс. ЭИИМ, дБВт | Official site. Офиц. сайт | | 54 | ECEE (FSS)
Sirius-4 | 12608H 12636H 12670H 12682V 12694V 12697H 12703V 12724V 12735H | 12500 - 12750 MHz | 3 x 72 MHz | 0 | |   | | bbcode: | |
|
| Teleports |
| # | Uplink | Owner: | D, m | Power, W | Site | Launched | Coordinates | | 315 | SES Astra
tp:
11766 H
12073 H
12130 V
| SES
Suedia
Solna, Sweden
tel. +46 8 505 645 00
fax. +46 8 28 24 80
info@ses-sirius.com
| 6,3 | 750 | Ukraine
, Kiev
гора Щекавица, Рател | 2010 | |  | bbcode:
315 | | # | Uplink | Owner: | D, m | Power, W | Site | Launched | Coordinates | | 350 | Тиса-1
Tisa-1
tp:
12670 H
| Закарпатська ОД ТРК Тиса-1
Ukraine
, Uzhhorod
Киевская набережная, 18
tel. (+38 3122) 61-62-72
fax. 3-23-76
| unknown | unknown | Ukraine
, Uzhhorod
Киевская набережная, 18 | | |
350 | | # | Uplink | Owner: | D, m | Power, W | Site | Launched | Coordinates | | 450 | Riga Skyport
tp:
11843 H
11900 V
11958 H
| SIRIUS Satellite Services Latvija
Latvia
Zakusalas krastmala 3. Of.204. LV-1509 Riga, Latvia
tel. +371 6 720 09 47
fax. + 371 6 720 09 46
| 3,7 | unknown | Latvia
Riga. Zakusalas krastmala 3 | 2002 | |       | bbcode:
450 | | # | Uplink | Owner: | D, m | Power, W | Site | Launched | Coordinates | | 900 | Stellar
tp:
12169 V
12207 V
| Stellar PCS GmbH
Germany
Goldenbergstrase 1a. 50354 Hurth-Cologne.
tel. +49 (0) 22 33-39 68-0
fax. +49 (0) 22 33-39 68-99
info@stellar-dbs.com
| 5,0 | unknown | Germany
Goldenbergstrase 1a. 50354 Hurth-Cologne. | | |         | | bbcode: | |
|
| |
|
|
|
| |
|
TRANSPONDER NEWS
|
|
|
Astra 4A, SES-5, 4.8° East
[19.05.23] 'RZR' is back on 12130 V, sr 27500, fec 3/4, MPEG-4, FTA [flysat.com] [10.05.23] 'Dim HD' has left 11747 V [forums.frocus.biz, KANDIK] [08.04.23] '5 Kanal (Ukraine)' has left 12284 V [flysat.com] [31.03.23] 'History 2', 'One Planet', 'Travel XP' has started on 12092 V, sr 30000, fec 2/3, DVB-S2 / 8PSK, MPEG-4, Verimatrix [forums.frocus.biz, yorick] [31.03.23] 'Viasat Explore', 'Viasat History', 'Viasat Nature' has left 12092 V [forums.frocus.biz, yorick] [17.03.23] 'TBN Ukraine' is back on 12380 H, sr 27500, fec 3/4, FTA [flysat.com] [12.03.23] 'Comedy Central Ukraine' has started on 11766 H, sr 30000, fec 2/3, DVB-S2 / 8PSK, MPEG-4, Verimatrix [forums.frocus.biz, mc4e] [12.03.23] 'Paramount Comedy' has left 11766 H [forums.frocus.biz, mc4e] [11.03.23] 'DOM TV' is back on 12130 V, sr 27500, fec 3/4, FTA [flysat.com] [11.03.23] 'RZR' has left 12130 V [flysat.com] | | News for this position only |
